Bosch Surface Mount request to Exit Detector, DS150i
The Bosch DS150i motion detectors are specifically designed for Request-to-exit applications, wall or ceiling mountable.
Model: DS150i
The DS150i Series consists of the DS150i Detector (light gray) and the DS151i Detector (black). They are specifically designed for Request-to-exit (REX) applications. The DS150i and DS151i detect motion in their coverage area and signal an access control system or door control device.
This type of detector is often used in commercial and industrial settings, such as office buildings, warehouses, and other facilities that require controlled access.
Alarm System Detectors
- Single or double door use
- Wall or ceiling mountable
- Internal vertical pointability
- Wrap-around coverage pattern
- Selectable relay trigger mode
- Selectable fail safe/fail secure modes
- DS150i is a passive-infrared detector designed for request to exit (REX) feature
| Current Draw: | 26 mA at 12 VDC |
| Voltage: | 12 VAC or VDC; 24 VAC or VDC |
| Alarm Output: | Two Form C relay contacts |
| Indicators: | One activation LED |
| Relay Latch Time: | Adjustable to 60 sec |
| Enclosure Dimensions: | 3.8 cm x 15.9 cm x 3.8 cm (1.5 in. x 6.25 in. x 1.5 in.) |
| Enclosure Material: | High impact ABS plastic enclosure |
| Power Loss Default Mode: | Programmable fail-safe or fail-secure modes. |
| Timer Mode: | Programmable reset (accumulative) or non-reset (counting) mode. |
| Mounting Location: | Surface mount on wall or ceiling |
| Operating Temperature: | -29°C to +49°C (-20°F to +120°F) |
| Radio Frequency Interference (RFI) Immunity: | No alarm or setup on critical frequencies in the range from 26 MHz to 1000 MHz at 50 V/m. |
Original: $97.39
-70%$97.39
$29.22Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
The Bosch DS150i motion detectors are specifically designed for Request-to-exit applications, wall or ceiling mountable.
Model: DS150i
The DS150i Series consists of the DS150i Detector (light gray) and the DS151i Detector (black). They are specifically designed for Request-to-exit (REX) applications. The DS150i and DS151i detect motion in their coverage area and signal an access control system or door control device.
This type of detector is often used in commercial and industrial settings, such as office buildings, warehouses, and other facilities that require controlled access.
Alarm System Detectors
- Single or double door use
- Wall or ceiling mountable
- Internal vertical pointability
- Wrap-around coverage pattern
- Selectable relay trigger mode
- Selectable fail safe/fail secure modes
- DS150i is a passive-infrared detector designed for request to exit (REX) feature
| Current Draw: | 26 mA at 12 VDC |
| Voltage: | 12 VAC or VDC; 24 VAC or VDC |
| Alarm Output: | Two Form C relay contacts |
| Indicators: | One activation LED |
| Relay Latch Time: | Adjustable to 60 sec |
| Enclosure Dimensions: | 3.8 cm x 15.9 cm x 3.8 cm (1.5 in. x 6.25 in. x 1.5 in.) |
| Enclosure Material: | High impact ABS plastic enclosure |
| Power Loss Default Mode: | Programmable fail-safe or fail-secure modes. |
| Timer Mode: | Programmable reset (accumulative) or non-reset (counting) mode. |
| Mounting Location: | Surface mount on wall or ceiling |
| Operating Temperature: | -29°C to +49°C (-20°F to +120°F) |
| Radio Frequency Interference (RFI) Immunity: | No alarm or setup on critical frequencies in the range from 26 MHz to 1000 MHz at 50 V/m. |
